High Viscosity Thickener Binder CMC Carboxymethylcellulose Sodium
High Viscosity Thickener Binder CMC Carboxymethylcellulose Sodium (1)Oil Drilling Grade CMC *Physical and Chemical Index
Basic Info
Model NO. | CMC (Carboxymethyl cellulose sodium) for Painting |
CAS No. | 9004-32-4 |
Mf | [C6h7o2(Oh)2CH2coona]N |
Einecs No. | 265-995-8 |
Classification | Chemical Auxiliary Agent Grade Oil Drilling Grade |
Purity | 95% |
Shelf Time | 2 Years |
pH | 5.0-8.0 |
Moisture | 10%Max |
Method | Water |
Safe | Physiologically and Toxicologically Harmless |
Transport Package | 25 Kg/Bag |
Specification | 300-2000mpa. s |
Trademark | KELAIDE |
Origin | China |
HS Code | 3912310000 |
Production Capacity | 30, 000 Mt Per Year |
Product Description
High Viscosity Thickener Binder CMC Carboxymethylcellulose SodiumWhat we have ? |
(1)Oil Drilling Grade CMC
*Physical and Chemical Indexes of Sodium Carboxymethyl Cellulose for Drilling Fluid.(Perform SY5093-92 Standard)
LV-CMC | MV-CMC | HV-CMC | |
Appearance | White or light yellow powder, freely flowable | ||
Replace degrees(D. S) | 0.80 min | ||
Purity | 80% min | 85% min | 95% min |
Viscosity 2%(in 2% solution at 25 centigrade) | 200-500 mpa.s | 600-900 mpa.s | 1000-1800 mpa.s |
Size(60 head) | 80% | ||
Moisture (%) | 10% max | ||
PH | 7.0-9.0 | 7.0-9.0 | 6.5-8.0 |
Category | Item | Index | ||
Distilled water | Salt water | Saturated salt water | ||
Oil-based mud | Filtration loss,ml | 60±10 | 90±10 | 100±10 |
Apparent viscosity,mpa.s | ≤6 | ≤6 | ≤10 | |
PH | 8.0±1.0 | 8.0±1.0 | 7.5±1.0 | |
HV-CMC | Pulping rate,m³/t | ≥200 | ≥150 | ≥160 |
LV-CMC | Filtration loss(10ml) | Dosage,g/l | ≤7.0 | ≤10.0 |
Apparent viscosity,mpa.s | ≤4.0 | ≤6.0 | ||
MV-CMC | Dosage,g/l | 6.0 | 14.0 | 3.5 |
Apparent viscosity,mpa.s | ≥15 | ≥15 | ≥15 | |
Filtration loss,ml | ≤9 | ≤9 | ≤8 |
(2)Paint Grade CMC
LV-CMC | MV-CMC | HV-CMC | |||
Appearance | White or light yellow powder, freely flowable | ||||
Purity | 75-85% min | 75-90% min | 80-90% min | ||
Viscosity 2%(in 2.5% solution at 30 centigrade) | 300-500 mpa.s | 400-700 mpa.s | 800-1200 mpa.s | ||
Moisture (%) | 7-10% | 6-10% | 7-10% |
Model | 2% viscosity,mpa.s | PH | Loss on drying,% | Purity% |
KLD7 | 600-800 | 7-9 | ≤10 | ≥65 |
KLD8-2 | ≥800 | 7-9 | ≤10 | ≥70 |
KLD8-4 | 800-1200 | 7-9 | ≤10 | ≥80 |
KLDT04 | ≥450 | 8-10 | ≤10 | |
KLDT02 | 250-300 | 8-10 | ≤10 | |
KLD348 | ≥300 | 8-12 | ≤40 | |
KLD248 | 100-200 | 8-12 | ≤40 | |
KLD148 | 40-100 | 8-12 | ≤40 |
What can you get from CMC? |
- CMC has a high ability to control water loss. In particular, PAC is a highly effective fluid loss reducer at lower dosages. You can control the loss of water to a higher level. It does not affect other properties of the mud.
- The formed mud cake is of good quality, strong and tough.
- It has good temperature resistance and excellent salt resistance. Under a certain salt concentration, it still has a good ability to reduce water loss and maintain a certain rheology. Compared to soluble in salt water and soluble in water, the viscosity hardly changes. Particularly suitable for offshore drilling and deep well requirements.
- It can well control the rheological properties of the mud. It has good non-Newtonian fluidity.
- In addition, KELAIDE® CMC is used as a cementing fluid to prevent fluids from entering pores and fractures. It is used as a fracturing fluid to control fluid loss into the well.
Where can you use CMC? |
1. "KELAIDE®" CMC is applied to water-based latex paint. It can meet the rheological properties of a certain flow under the action of brush or roller shear force.
2. It can control viscosity and suspension.
3. Generally, CMC accounts for 1-3% in water-based paints and coatings.
